Xenbase Image ID: 40732

Fig. 2. In situ hybridization of selected secretory pathway genes to Xenopus embryos. (A-K′) Embryos at stage 12.5 (A-K), stages 15-17 (A′-K′) and stages 28-32 (A′-K′). All of these genes show preferential expression in the notochord, and some also show expression in the pronephros (red triangle). Image published in: Tanegashima K et al. (2009) Copyright © 2009. Image reproduced with permission of the Publisher and the copyright holder. This is an Open Access article distributed under the terms of the Creative Commons Attribution License. Gene Synonyms Species Stage(s) Tissue copz1.L copz, zeta1-cop X. laevis Throughout NF stage 12.5 axial mesoderm cope.S X. laevis Throughout NF stage 12.5 axial mesoderm large1.L large, LOC108704366, LOC108712551, mdc1d X. laevis Throughout NF stage 12.5 axial mesoderm sec61g.L sec61g-a, sec61g-b, sss1 X. laevis Sometime during NF stage 12.5 to NF stage 17 notochord schip1.S Sec22L1 X. laevis Sometime during NF stage 12.5 to NF stage 17 notochord sec62.S TLOC1 X. laevis Sometime during NF stage 12.5 to NF stage 32 notochord rrbp1.L X. laevis Sometime during NF stage 12.5 to NF stage 32 notochord hspa5.S BiP, grp78, immunoglobulin-binding protein, XAP-1 X. laevis Sometime during NF stage 12.5 to NF stage 32 notochord hsp90b1.L ecgp, gp96, grp94, tra1 X. laevis Sometime during NF stage 12.5 to NF stage 32 notochord pronephric kidney dnajb9.L MGC53411 X. laevis Sometime during NF stage 12.5 to NF stage 32 notochord cope.S X. laevis Throughout NF stage 17 notochord copz1.L copz, zeta1-cop X. laevis Throughout NF stage 17 notochord large1.L large, LOC108704366, LOC108712551, mdc1d X. laevis Throughout NF stage 17 notochord cope.S X. laevis Throughout NF stage 28 notochord cement gland copz1.L copz, zeta1-cop X. laevis Throughout NF stage 28 notochord somite tail bud cement gland head large1.L large, LOC108704366, LOC108712551, mdc1d X. laevis Throughout NF stage 28 mesoderm notochord pronephric kidney cement gland tail bud sec61g.L sec61g-a, sec61g-b, sss1 X. laevis Sometime during NF stage 28 to NF stage 32 pronephric kidney schip1.S Sec22L1 X. laevis Sometime during NF stage 28 to NF stage 32 pronephric kidney Image source: Published Larger Image Printer Friendly View
