Zookeys
2015 Jan 19;472:1-25. doi: 10.3897/zookeys.472.8547.
Show Gene links
Show Anatomy links
Southern hemisphere deep-water stylasterid corals including a new species, Errinalabrosa sp. n. (Cnidaria, Hydrozoa, Stylasteridae), with notes on some symbiotic scalpellids (Cirripedia, Thoracica, Scalpellidae).
Pica D
,
Cairns SD
,
Puce S
,
Newman WA
.
???displayArticle.abstract???
A number of stylasterid corals are known to act as host species and create refuges for a variety of mobile and sessile organisms, which enhances their habitat complexity. These include annelids, anthozoans, cirripeds, copepods, cyanobacteria, echinoderms, gastropods, hydroids and sponges. Here we report the first evidence of a diverse association between stylasterids and scalpellid pedunculate barnacles and describe a new stylasterid species, Errinalabrosa, from the Tristan da Cunha Archipelago. Overall, five stylasterid species are found to host eight scalpellid barnacles from several biogeographic regions in the southern hemisphere (Southern Ocean, temperate South America and the southern Indo-Pacific realms). There is an apparent lack of specificity in this kind of association and different grades of reaction to the symbiosis have been observed in the coral. These records suggest that the association between pedunculate barnacles and hard stylasterid corals has a wide distribution among different biogeographic realms and that it is relatively rare and confined largely to deep water.
Figure 1. Stephanohelia sp. a Colony. SEM micrographs of b branch with polychotomous tiny branches and male ampullae c small abcauline spines d texture e polychotomous branches with aligned dactylopores f gastrostyle g female ampulla.
Figure 2. Errina
fissurata Gray, 1872. a Colony. SEM micrographs of b apical branch c–d reticulate-granular coenosteal texture e gastrostyle f bifurcating spines of gastrostyle g different type of pores: gastropore (black arrow), large dactylopore spine (yellow arrow), small dactylopore spine (orange arrow) and large round pore (red arrow) h large dactylopore spine (yellow arrow), small dactylopore spines (orange arrows) and large round pore (red arrow) i large adcauline dactylopore spines j dactylostyles k small dactylopore spine l female ampulla m male ampulla.
Figure 3. Errina
labrosa sp. n. a–b Holotype. SEM micrographs of c spiny branch apex with gastropores and dactylopores uniformly distributed d middle portion of the colony e lateral view of the colony branch with gastropores are aligned and surrounded by the dactylopores f superficial coenosteum without pore g texture reticulate-granular h gastropore with lip i gastropore without lip.
Figure 4. Errina
labrosa sp. n. SEM micrographs of a gastrostyle b multitipped bifurcating spines of the gastrostyle c diffuse ring palisade d–f dactylopores from the apical region to the base.
Figure 5. Errina
labrosa sp. n. SEM micrographs of a dactylopore without spine b dactylostyle c–d ampullae.
Figure 6. Errina
fissurata. a Specimen with Trianguloscalpellum sp. b SEM of Trianguloscalpellum sp. c specimen with Ornatoscalpellum
cf.
vanhoeffeni
d peduncular plates in cavity in coral coenosteum e SEM of where a barnacle was detached (yellow arrow) next to a superficial bump (white arrow) f peduncular scales in a bump g young barnacles one with peduncle in a dactylopore (arrow).
Figure 7. a–b Peduncle of Arcoscalpellum sp. 1 not covered by coenosteum of Errina
labrosa sp. n. c–d Peduncle of Arcoscalpellum sp. 2 not covered by coenosteum in Inferiolabiata
spinosa and SEM micrograph of same species e scalpelline sp. 2 concentrated in the basal portion in Errina
antarctica
f peduncle Ornatoscalpellum
cf.
gibberum attached to but free of coral skeleton in Errina
antarctica
g circular bumps with little depressions on the top in Errina
antarctica
h scalpelline sp. 3 with peduncle fully and lower margin of capitulum partially covered by the calcareous skeleton of Stephanohelia sp.
Cairns,
Global diversity of the Stylasteridae (Cnidaria: Hydrozoa: Athecatae).
2011, Pubmed
Cairns,
Global diversity of the Stylasteridae (Cnidaria: Hydrozoa: Athecatae).
2011,
Pubmed
Cairns,
Stylasteridae (Cnidaria, Hydrozoa, Filifera) from South Africa.
2013,
Pubmed
Roberts,
Reefs of the deep: the biology and geology of cold-water coral ecosystems.
2006,
Pubmed
Simon-Blecher,
Phylogeny of coral-inhabiting barnacles (Cirripedia; Thoracica; Pyrgomatidae) based on 12S, 16S and 18S rDNA analysis.
2007,
Pubmed
