Zookeys
2016 Nov 21;634:1-14. doi: 10.3897/zookeys.634.9769.
Show Gene links
Show Anatomy links
A new species of Pentamera Ayres, 1852 from the Brazilian coast (Holothuroidea, Dendrochirotida, Phyllophoridae).
Prata J
,
Christoffersen ML
.
Abstract
Pentamera paraibanensissp. n. is described from more than 3000 specimens as a new species of Phyllophoridae from northeast Brazil, in the tropical southwestern Atlantic. It is distinguished from its congeners by the shape of the calcareous ring with moderate posterior processes, and by the tables in the body wall with a usually quadrilocular disc and a low, toothed spire composed of two pillars. The body is brown, with the tube feet in double rows per ambulacrum, and tentacles more lightly colored. The species was found inside rodoliths in large numbers. This paper contains a morphological description of the specimens, and an account of their habitat characteristics.
Figure 1.
Pentamera
paraibanensis sp. n. External view of holotype, A Dorsal B Ventral C Lateral D External view of specimen UFPB.ECH-2048, E External view of specimen UFPB.ECH-2058
F External view of specimen UFPB.ECH-2089. G Calcareous ring H Rosette of tentacles I Table from body wall J Support tables from tube feet.
Figure 2.
Pentamera
paraibanensis sp. n. A Rosettes from tentacles B Rods from tentacles C Rosettes from introvert D Tables from dorsal body wall E Support plates from dorsal tube feet F Base of support tables from dorsal tube feet G Support tables from dorsal tube feet H Tables from ventral body wall, the more elongated table was found near the anus I Large plate of tube feet.
Figure 3.
Pentamera
paraibanensis sp. n. A Support plates from ventral body wall B Base of support tables from ventral tube feet C Curved base of support tables from ventral tube feet D Support plate of tube feet E Support tables from ventral tube feet F Curved support tables from ventral tube feet G Large plate from body wall near the anus H Endplate from dorsal tube feet I Endplate from ventral tube feet J Anal tooth.
